Description: Current Sense Amplifiers 26-V, Bi-Directional, Zero-Drift, High Accuracy, Low-/High-Side, Voltage Out Current Shunt Monitor 6-SC70 -40 to 125
Operating Supply Current :: |
65 uA |
Ib - Input Bias Current :: |
35 uA |
Mounting Style :: |
SMD/SMT |
Vcm - Common Mode Voltage :: |
- 0.1 V to + 26 V |
Minimum Operating Temperature :: |
- 40 C |
Supply Voltage - Max :: |
26 V |
Package / Case :: |
SC70-6 |
Maximum Operating Temperature :: |
+ 125 C |
Packaging :: |
Reel |
Supply Voltage - Min :: |
2.7 V |
Product Category :: |
Current Sense Amplifiers |
Series :: |
INA212 |
GBP - Gain Bandwidth Product :: |
4 kHz |
Number of Channels :: |
1 Channel |
Vos - Input Offset Voltage :: |
0.55 uV |
Manufacturer :: |
Texas instruments |
CMRR - Common Mode Rejection Ratio :: |
105 dB |
Operating Supply Current :: |
65 uA |
Ib - Input Bias Current :: |
35 uA |
Mounting Style :: |
SMD/SMT |
Vcm - Common Mode Voltage :: |
- 0.1 V to + 26 V |
Minimum Operating Temperature :: |
- 40 C |
Supply Voltage - Max :: |
26 V |
Package / Case :: |
SC70-6 |
Maximum Operating Temperature :: |
+ 125 C |
Packaging :: |
Reel |
Supply Voltage - Min :: |
2.7 V |
Product Category :: |
Current Sense Amplifiers |
Series :: |
INA212 |
GBP - Gain Bandwidth Product :: |
4 kHz |
Number of Channels :: |
1 Channel |
Vos - Input Offset Voltage :: |
0.55 uV |
Manufacturer :: |
Texas instruments |
CMRR - Common Mode Rejection Ratio :: |
105 dB |
